$2000+

Suitable for all metal materials such as steel, iron, copper, aluminum, gold, and silver, and some non-metal materials including PC, ABS, etc. It is mainly used in fields that require high smoothness and fineness, such as electronic products, hardware and sanitary ware, watches, watches, jewelry, etc.

Features

1. Ultra-high configuration: optional domestic or imported lasers and high-speed galvanometers.
2. No maintenance required: The laser requires no maintenance, no need to adjust or clean the lens, and its average working time can reach 100,000 hours.
3. No consumables required: No consumables required, non-toxic, no environmental pollution, and highly environmentally friendly.
4. Red light positioning: Using red light positioning system, positioning is convenient and has high positioning accuracy.
5. Extended functions: Additional functions can be expanded. Such as circular marking, X Y electric worktable, automatic feeding and flying marking, etc.
6. Depth marking: High-speed scanning galvanometer can mark the workpiece white, black and deep.
7. Computer programming: printing occurs automatically, printing English, numbers, Chinese characters, graphics, and the printing content can be changed at will.
8. Multiple fonts: common one-dimensional barcodes and DatamatrixPDF417 two-dimensional barcodes.

Technical Parameters

Use manual training

• Straight lines, diagonal lines and arc markings
• Font library to optimize output to the greatest extent
• Marking preview
• Multiple frequencies to whiten and blacken workpieces
• Adjustable power
• Allows you to easily complete multiple tasks: duplicate checks, history files, administrator login
• Obtain data from existing systems or code reading guns
• Supports PLT, PCX, DXF, BMP and other files, SHX, TTF font libraries.
• Software extensible flight markers.
• Automatic serial number, date and time can be set according to production needs.
• Open multi-language, can easily support languages ​​​​around the world.
• Powerful filling function, supports ring filling.

Configuration

After the customer purchases the machine, the customer will be provided with a 24-month warranty.
Lifetime maintenance service.

Security Information

Before using this product, please read and understand this product introduction and familiarize yourself with the information we provide you. This product fact sheet provides important product operating, safety, and other information For your reference and all future users.
Class IV laser products. Before turning on the main power supply, make sure that the correct AC220V power supply is connected. Incorrect connection of the power supply will damage the equipment.

• The device emits more than 20W (according to different models) laser radiation in the 1064nm wavelength range. Avoid direct contact with the eyes and skin or the direct emission or scattering of light from the output end.of radiation.
• Do not open the core laser as there are no product parts or accessories available to the user. All maintenance or repairs may only be performed within Feijie.
• Do not look directly at the output head, and be sure to wear laser safety glasses when operating the device.
• Post laser warning signs and detailed laser operating precautions in the workplace.

Warning:

There is danger of laser radiation here, avoid looking directly.

• The laser beam will burn clothes, paper and other flammable items. The light path should avoid flammable items.
• Laser is easy to ignite and explode flammable and explosive substances (such as alcohol, gasoline, hydrogen, gunpowder, etc.). The light path should avoid flammable and explosive substances.
