The LX9000 series of CIJ printers offers manufacturers with the simplest, most reliable, and efficient coding solution, with a rich production line speed, minimal maintenance, and increased efficiency.
The LINS-JET9000 series of CIJ printers offers manufacturers with the simplest, most reliable, and efficient coding solution, with a rich production line speed, minimal maintenance, and increased efficiency.
Small Character InkjetPrinter
Small Character InkjetPrinter
Prompt response, Skeuomorphic design, better affordance, minimized learning curve of human printer interaction.
Simply, friendly operating, reduced learning curve,more feedback.
Enhanced remote control by RS485 & RJ45 on printer.
Compact printer design, easy to integrate in manufacturing lines or equipments.
Stainless steel cabinet, robust, hygienic, corrosion resistant.
Improved user experience by new 10 inch touchscreen and UI design.
430m/min ultra-high-speed printing.
20 languages available, enhanced print quality in high speed printing.
Designed for simplicity.
Integrated ink module design, surface mount main filter tosimplify maintenance of printers.
Printhead interior circuits are fully sealed by outstanding dielectric strength and corrosion resistant epoxy to ensure robust printhead performance throughout entire printer life.
Main circuit board in printer came from original design and rigorous test, late semiconductors were chosen to empower reliability and versatility of printers.
| MODEL | LINS-JET9000 | LINS-JET9000H |
|---|---|---|
| Material | Stainless steel | Stainless steel |
| MaxLiensofPrint | 1-4 Line（s 7X5matrix） 1-5 Line（s 5X5matrix） | 1-4 Line（s 7X5matrix） 1-5 Line（s 5X5matrix） |
| Max. speed @5X5 | 206m/min | 430m/min |
| Industrial Protection | IP55 | IP55 |
| Printhead | 3M conduit Nozzlesize:60um | 3M conduit Nozzlesize:60um |
| Font Matrix | Single-Line:5X5,7X5,9x6,12X8,16X11,19X14,24X17,32X22 Twin-Line:5X5,7X5,9x6,12X8,16X11 3 Lines:5X5,7X5,9x6 4 Lines:5X5,7X5 5 Lines:5X5 |
| Character HeightRange | Font height: 1-15mm Printingditsance:2mm-30mmBest: 10mm |
| System | 10 Inch - Touch Screen, Linux System |
| PrintContent | English,Chinese,Arabic Numbers, Serialnumber,Barcode, Shift,DM/QR Code, UPCA&E, EAN 8&13,GS1,Logo, UCC/EAN 128,Code 128A,B&C,Code39,Code125,Automaticdate/time/expirydate, Apecialcharacters,etc. |
| Extra Memoy | USB,RS485,Ethernet |
| System Language | Chinese, English, Korean, Russian, Polish, Persian, Arabic, Spanish, German, Indonesian, Vietnamese, Croatian, Thai, Slovenian, Slovak, Bosnian, Portuguese, Italian, etc. Available for language customization. |
| Memory Storage | 1000+Messages |
| Printing Direction | 360º All-round printing |
| Cartridge Volume | Ink (500ml) Make-up (750ml) |
| Temperature/Humidity range | 0-50℃ 0-95% Relative Humidity, Non-condensing |
| Power | 100-120/200-240V 50/60Hz,0.72/0.36A,80W |
